Non Destructive Testing For Cracks
Non destructive testing and evaluation is used in a wide variety of industries such as power production, construction, oil and gas industries, nuclear power and more. Non destructive testing companies employ certified, expert staff who are trained in highly specialised methods of testing the composition and integrity of materials. Many industries are required by law to conduct regular non destructive testing to ensure equipment functions efficiently and safely and complies with certification regulations. In many cases, for example transporting oil and gas or nuclear power, the presence of cracks or other weaknesses in storage containers or pipelines could have catastrophic consequences. A crack in any material is a point of weakness and any stresses put on the material could lead to the crack widening and leading to shearing and splitting. Cracks can occur during manufacture, as a result of poor welding or due to stresses placed on equipment during work
The main advantages of non destructive testing are that it can often be carried out on site or while equipment is working, reducing the need for shutdowns or delays in work. Non destructive testing equipment, while highly sensitive, is usually easily portable. There are four main non destructive testing methods used to detect cracks, depending on the materials being inspected.
Methods of testing
- Visual Inspection – Visual inspection is a means of testing that can expose a variety of physical flaws that could compromise structural integrity in working machinery or components being manufactured. Although this can be as basic as a trained inspector looking over the surface in detail, there is a variety of optical equipment that can be used to inspect the surface of the material, such as borescopes and flexible fibre optics to examine the inside of pipes or containers. These can be combined with video surveys to give evidence that can be carefully examined at a later time. This technique is usually used to test welding joins for cracks that could weaken the join but can be applied to a variety of items and materials. Due to its simplicity, this is the oldest type of non destructive testing and popular due to its low cost.
- Ultrasonic testing – This is a more technical type of inspection that can be used on all materials, metallic and non metallic but has the greatest resolution on metals. It uses very short ultrasonic pulse waves, usually from 0.1 to 15 MHz in frequency, that are transmitted into the material to be inspected from a transducer. A liquid such as oil or water (known as a couplant) is applied to the surface of the material to facilitate this. The reflected ultrasonic pulses are then measured by the transducer. The speed of the reflected pulses will be altered by any imperfections such as cracks and this will be sensed by the transducer. In another variation of this method, known as attenuation, an emitter sends ultrasonic pulses through the material and a receiver further along the surface picks them up. Any flaws in the material will affect the pulses, revealing the presence of any damage.
- Magnetic Particle testing – This type of inspection is used on ferromagnetic metals (magnetisable metals such as iron, cobalt or nickel, or their alloys). Very fine ferromagnetic particles are applied to the surface of the material, either dry or suspended in a liquid and the local area of the material is then magnetised. This is known as magnaflux testing and the magnetisation can be provided by an outside source (indirect magnetisation) or by passing an electrical current through the metal (direct magnetisation). If the metal is intact the magnetic flux will be retained within the metal, however if there is a break in the metal such as a crack, the magnetic flux will leak around the flaw and the ferromagnetic particles will be attracted and concentrate around the crack. This will show the location and size and shape of the crack. To identify smaller cracks or imperfections, an ultraviolet light can be used to more easily observe the particles. Once the magnetic particle inspection is complete, the area is demagnetised.
- Dye penetrant inspection – This is also known as liquid penetrant testing and involves applying a coloured liquid by spraying, brushing or dipping to a surface that has been thoroughly cleaned. Due to the liquid involved this method is unsuitable for porous materials. This is then given what is known as ‘dwell time’ to take effect (typically from five to thirty minutes depending on the specific liquid used). The liquid will flow into any cracks in the surface by capillary action, the smaller the crack the longer this will take. Once the dwell time is complete, excess penetrant is removed from the surface of the material being tested and a developer is applied to the surface and given time to take effect. The developer will draw penetrant from any cracks or other imperfections, known as ‘bleed out’, making them visible to the naked eye of the trained observer. A more rigorous form of dye penetrant test uses a fluorescent dye that can only be seen under ultraviolet light. Although this can be more expensive even the smallest cracks or flaws will be easily visible.
Radiographic Testing
Radiographic testing is a powerful non-destructive testing method used to detect internal flaws in various materials. This technique involves the use of X-rays or gamma rays to produce images of the internal structure of the tested object. The radiation passes through the material and is captured on a detector or film placed on the opposite side. Differences in material density and thickness affect the amount of radiation that reaches the detector, creating a detailed image that reveals any internal cracks, voids, or inclusions. Radiographic testing is particularly useful for inspecting complex structures and assemblies, such as welded joints, castings, and composite materials. It provides a permanent record of the inspection, which can be analysed and archived for future reference. This method is widely used in industries where safety and reliability are critical, such as aerospace, automotive, and oil and gas. One of the main advantages of radiographic testing is its ability to detect internal defects without requiring disassembly of the inspected components. However, it requires strict safety measures due to the use of ionising radiation, and the equipment is typically more cumbersome compared to other non-destructive testing methods.
Infrared Thermography
Infrared thermography is a non-contact, non-destructive testing technique that uses infrared cameras to detect thermal anomalies on the surface of materials. This method is based on the principle that defects, such as cracks or voids, can affect the thermal conductivity of a material, causing temperature variations that can be detected with infrared imaging. Infrared cameras capture the thermal radiation emitted by the object’s surface, producing a thermal image or thermogram that highlights areas with abnormal temperatures. This technique is highly effective for detecting surface and near-surface defects, such as delaminations, corrosion, and impact damage, especially in non-metallic materials like composites and ceramics. Infrared thermography is widely used in the aerospace, automotive, and building inspection industries for preventive maintenance and quality control. It allows for rapid scanning of large areas and provides immediate visual results, making it an efficient tool for routine inspections. One of the key benefits of infrared thermography is its ability to inspect objects in real-time and under operational conditions, without requiring shutdowns or interruptions. Additionally, it is a safe and non-invasive method, as it does not involve the use of radiation or physical contact with the tested material. However, it may be less effective in detecting internal defects located deep within the material, and its accuracy can be influenced by environmental factors such as ambient temperature and airflow.
